鑽石塗層束線與絞線模 | 金剛石塗層束線與絞線模 Diamond coated bunching and stranding dies
束線，絞線與擠壓模具常用於多線電纜的生產。一個束線或絞線模具是將單線和多線組織起來，然而擠壓模具則是將多線擠壓成要求的形態。
ESTEVES集團先進的鑽石塗層技術以及嚴格的尺寸公差控制給電纜公司節約的材料和製造成本。
束線，絞線與擠壓模具常用於多線電纜的生產。一個束線或絞線模具是將單線和多線組織起來，然而擠壓模具則是將多線擠壓成要求的形態。
ESTEVES集團先進的鑽石塗層技術以及嚴格的尺寸公差控制給電纜公司節約的材料和製造成本。
自華光電 - 荷蘭Esteves Group鑽石眼模/異形眼模 台灣代理商。
Allen K. Lin | Allen@myblossom.tw | LINE ID: Allen-007 | Wechat ID: Allen-006 | T: 0910-782775
Diamond coated bunching and stranding dies
Featured
Featured
Bunching, stranding and compacting dies are often used to form multi-wire electrical cables. A bunching or stranding die groups single and multiple wires together, whereas a compacting die compacts the multi-wire strand to the required form factor.
State-of-the-art diamond coating technology and tight diameter tolerances of Esteves Group diamond coated dies give the cable company the ability to save material and manufacturing costs.
Blank (Nib) material
State-of-the-art diamond coating technology and tight diameter tolerances of Esteves Group diamond coated dies give the cable company the ability to save material and manufacturing costs.
Blank (Nib) material
Carbide, coated with layer of diamond.
The reasonably thick ultra-smooth layer of diamond on a tungsten carbide die ensures the smoothest wire and cable surface that is possible today. The diamond coated die is the ideal combination of large-size availability of tungsten carbide and the ideal surface properties of randomly oriented synthetic diamond.
Casing
The reasonably thick ultra-smooth layer of diamond on a tungsten carbide die ensures the smoothest wire and cable surface that is possible today. The diamond coated die is the ideal combination of large-size availability of tungsten carbide and the ideal surface properties of randomly oriented synthetic diamond.
Casing
Stainless steel
Geometry
Geometry
Size range from 8 to 77 mm (.315 to 3.03”).
Angle range is generally 18 to 24 degrees plus or minus 2 degrees.
Bunching and stranding dies have a well-blended profile with no sharp edges.
