首德 D263 玻璃晶圓,SCHOTT D263 Glass wafers
肖特 D263 玻璃晶圓,SCHOTT D263 Glass wafers
Plan Optik D263玻璃晶圓,Plan Optik D263 Glass wafers

熱膨脹係數(CTE): 7.2 ppm/°C

Plan Optik 生產多種客製化玻璃和石英晶圓,從小量產品到大量都有。直徑測量介於 50 到 300 mm 的低厚度公差和低 TTV 值。

Plan Optik 所生產的客製化晶圓用來生產光學或是化學偵測器,壓力傳感器和加速度傳感器。典型的應用工業領域在消費性電子部門(CMOS 影像偵測,微反射鏡),汽車產業(壓力傳感器,如輪胎,引擎控制),航天(三維加速度傳感器),化學(微反應技術),藥品(實驗室芯片)和一般的半導體生產。


自華光電 - 德國Plan Optik AG 玻璃晶圓/石英晶圓/載體晶圓 台灣獨家代理商。

Allen K. Lin | Allen@myblossom.tw | LINE ID: Allen-007 | Wechat ID: Allen-006 | T: 0910-782775


Plan Optik produces customized wafers from various types of glass and quartz, from single-item production to large-scale series. The diameter measures between 50 - 300 mm with low thickness tolerances and low ttv values.

Customized wafers by Plan Optik are used to manufacture optical or chemical sensors, pressure sensors and acceleration sensors. Typical industrial areas of application lie in the consumer electronics sector (CMOS imaging, micro mirrors), automotive sector (pressure sensors, e.g. tires, engine control), aerospace (3D acceleration sensors), chemistry (micro reaction technology), pharmaceuticals (Lab-on-chip) and in semiconductor production in general.
