人工合成單晶鑽石伸線眼模 /人工合成單晶金剛石拉絲模具 (111面) SSCD - Diamond dies - Synthetic single crystal diamond wire dies (111 oriented)

伊斯特偉斯集團可供應高品質,經久耐用的人工合成單晶金剛石模具(SSCD,是人工合成單晶金剛石的簡稱)。該模具可應用於有色金屬及非有色金屬拉絲行業,尺寸範圍為0.010-1.81毫米(.00039-.0713英寸),更大尺寸可根據客戶需求定制。

與伊斯特偉斯集團其它產品一樣,人工合成單晶金剛石模具的製造過程嚴格執行一貫的高品質、高精度的標準。

人工合成單晶金剛石,縮寫為SSCD,SMCD或MCD,是一種在受控條件下人工合成的金剛石,它具有高純淨度,無雜質及無裂紋的特點。這些品質特性也使得拉絲模具的使用壽命比較穩定並具有可預測性。

伊斯特偉斯集團使用的都是<111>面的人工合成單晶金剛石,鑽石取向角度誤差控制在1度之內。使用<111>面的金剛石可確保模具磨損過程中仍然保持較好的圓整度,這一點只有尺寸較小的天然金剛石可以實現。

人工合成單晶金剛石的另外一個優點是可選擇的尺寸規格比較多,在模具擴孔過程中實現金剛石的最佳利用效率。

伊斯特偉斯集團SSCD模具的優勢
• 極高的硬度和抗磨損度確保了模具的使用壽命很長
• 模芯外形尺寸得到保證,因此可預測最大擴孔尺寸
• 所有模芯都是<111>面取向,最大限度地減少模具使用壽命的不穩定性,磨損形狀的不規則性,獲得最長的使用壽命。
• 得益於其極好的散熱性能,可用於高溫加工工藝
• 安裝方便,拉絲順暢
• 所有模芯都是在受控條件下製造,無雜質,無裂紋。
• 由於SSCD是人工合成的金剛石,它的品質與一致性得到保證。
• SSCD是非導電體,對於不適用導電介質模芯的場合是個不錯的選擇。

Esteves Group 伊斯特偉斯集團,全球模具公司:

飛利浦鑽石工具公司,西班牙伊斯特偉斯模具公司,美國迪凱特線模公司及UKD模具公司這四家因高品質及高精度模具產品而享譽全球的公司走到了一起。

聚晶鑽石眼模、合成單晶鑽石眼模、天然鑽石眼模、鎢鋼模、擠出工具、導向模、束線模/絞線模、拼合模、異型眼模。


自華光電 - 荷蘭Esteves Group 鑽石眼模/異形眼模/異形鑽石眼模台灣獨家代理商。

Allen K. Lin | Allen@myblossom.tw | LINE ID: Allen-007 | Wechat ID: Allen-006 | T: 0910-782775




Diamond dies - Synthetic single crystal diamond wire dies (111 oriented)

Esteves Group is a manufacturer of diamond drawing dies with synthetic single crystal diamond (SSCD, also known as single crystals) blanks inside as a high quality, predictable and durable product for drawing ferrous and non-ferrous wires from 0.010 to 1.81 mm (.00039 - .0713”). Larger sizes are available upon request.

Like all products from Esteves Group you can expect these products to be manufactured with the highest quality and accuracy standards.

Synthetic single crystal diamonds, also called synthetic mono crystal diamond and abbreviated as SSCD or SMCD or MCD, are man-made diamonds, manufactured under controlled conditions and are free from impurities, inclusions and cracks. These tightly controlled quality aspects lead to predictable and constant die performance.

The SSCD blanks that Esteves Group uses are all <111> oriented with a divergence in the orientation less than 1°. The result is a close-to-round wear pattern for each die, a quality aspect that previously could only be obtained in small natural diamond dies.

Another advantage of SSCD blanks is their availability in several sizes, allowing you to select the diamond blank that best fits your recut program.

Key benefits of Esteves Group SSCD diamond wire dies
• Long die life due to its extreme hardness and resistance to scratching
• Predictable recut dimensions as its blank dimensions are guaranteed
• Minimal variation in die life, wear shape variation, and optimal die life due to the <111> orientation
• Can be used in high-heat processes because of its extreme thermal conductivity
• Easy setup, smooth drawing
• All blanks have been manufactured under tightly controlled conditions and are free from impurities, inclusions and cracks
• As SSCD blanks are man-made single crystal diamonds, its product quality and consistency is guaranteed
• Nonconductive properties make this product a good choice when electrical conductive materials are an issue
