束線模/絞線模 Bunching and stranding dies
自華光電 - 荷蘭Esteves Group鑽石眼模/異形鑽石眼模 台灣代理商。
Allen K. Lin | Allen@myblossom.tw | LINE ID: Allen-007 | Wechat ID: Allen-006 | T: 0910-782775
Dies used to guide and/or form wires entering, moving through, and/or exiting bunching and stranding machines.
In the case of double and single twist bunchers, with the take-up reel on the inside of the machine, the dies are located at the entrance of the machine to gather the incoming wires.
Sometimes, the dies are located before the take-up reel inside the machine to shape the wire that goes onto the reel.
In the case of tubular and planetary stranders, stranding dies are used inside the machine to guide the wires and to gather and form the wire prior to going on the reel outside of the machine.
Blank (Nib) material
Carbide, PCD, natural diamond, synthetic single crystal, ceramic.
Casing
Casing
Stainless and cold rolled steel.
Geometry
Geometry
Size ranges from 0.380 mm to over 35 mm (.015” to over 1.38”) depending on the cable size being manufactured.
Tolerance is generally plus or minus 1% of the hole diameter.
Angle range is generally 18 to 24 degrees plus or minus 2 degrees.
Bunching and stranding dies must have a well-blended profile with no sharp edges.
Design considerations
Tolerance is generally plus or minus 1% of the hole diameter.
Angle range is generally 18 to 24 degrees plus or minus 2 degrees.
Bunching and stranding dies must have a well-blended profile with no sharp edges.
Design considerations
Entrance (Bell)
The entrance of a bunching or stranding die must be wide enough to accept the incoming wires from the lay-plate without scraping.
Reduction angle
Reduction angle
The standard angle is 20 to 24 degrees. The wider angle allows for a good blend from the entrance to the reduction angle.
Bearing length
Bearing length
The bearing length for random bunched wires is not critical. The purpose of the die is to gather the wires from the lay plate and direct them into the machine. The bearing length for concentric and unilay constructions is usually longer to help hold the wires in position as they enter the machine.
